Configuring Learned Port Security Sample Learned Port Security Configuration
OmniSwitch 6800/6850/9000 Network Configuration Guide March 2008 page 3-3
Sample Learned Port Security Configuration
This section provides a quick tutorial that demonstrates the following tasks:
• Enabling LPS on a set of switch ports.
• Defining the maximum number of learned MAC addresses allowed on an LPS port.
• Defining the time limit in which source learning is allowed on all LPS ports.
• Selecting a method for handling unauthorized traffic received on an LPS port.
Note that LPS is supported on Ethernet and gigabit Ethernet fixed, mobile, tagged and authenticated ports.
Link aggregate and tagged (trunked) link aggregate ports are not eligible for LPS monitoring and control.
1 Enable LPS on ports 6 through 12 on slot 3, 4, and 5 using the following command:
-> port-security 3/6-12 4/6-12 5/6-12 enable
2 Set the total number of learned MAC addresses allowed on the same ports to 25 using the following
command:
-> port-security 3/6-12 4/6-12 5/6-12 maximum 25
3 Configure the amount of time in which source learning is allowed on all LPS ports to 30 minutes using
the following command:
-> port-security shutdown 30
4 Select shutdown for the LPS violation mode using the following command:
-> port-security 3/6-12 4/6-12 5/6-12 violation shutdown
Note. Optional. To verify LPS port configurations, use the port-security learn-trap-threshold command.
For example:
-> show port-security
Port: 1/30
Operation Mode : DISABLED,
Max Bridged MAC allowed : 1,
Max Filtered MAC allowed : 5,
Low End of MAC Range : 00:00:00:00:00:00,
High End of MAC Range : ff:ff:ff:ff:ff:ff,
Violation Setting : RESTRICT,
MAC VLAN MAC TYPE
-------------------+------+-------------------
00:20:95:00:fa:5c 1 STATIC
To verify the new source learning time limit value, use the show port-security shutdown command. For
example:
-> show port-security shutdown
LPS Shutdown Config = 2 min
Convert-to-static = DISABLE
Remaining Learning Window = 110 sec
