Alecto DOS-560C User Manual

FUNCTIONS
Monitor (fig.1):
1. A B C D: indication which channel is displayed
2. SCAN: lights when the SCAN function is activated
3. VOLUME: volume control
4. OFF-ON-LCD OFF: OFF: monitor switched OFF
ON: monitor switched ON
LCD OFF: monitor switched ON but without image
5. CHANNEL: selection button channel-1 ~ channel 4
6.
and : brightness adjustment
7. 12V DC: power input connector 12VDC / 600mA
8. AV OUTPUT: output for recording on a VCR or for connecting
to a standard TV set
Camera (fig.2):
1 Infrared LED’s: illuminates close objects in a dark surrounding
2 CCD-Camera lens: delivers sharp image to the CCD sensor.
3 Channel-LED’s: indication selected channel
4 Mic.: built-in microphone
5 OFF 1 2 3 4 : power switch of the camera / selector switch
between the 4 channels
6 DC-jack: power input connector 9VDC / 500mA
