Alecto DVB-100 Mini NVR User Manual

-29-
External Ports Video Input 4×(1280*720) +sub[960*576]+4Ref.+4Play 4CH 720P IP Cameras
4×(1280*960)+sub[960*576]+1Ref.+4Play 4CH 960P IP Cameras
4×(1920*1080)+sub[960*576]+4Ref.+1Play 4CH 1080P IP Cameras
1×(1920*1080)+sub[960*576]+4Ref.+1Play 1CH 1080P IP Cameras
4×(720*576) +sub[352*288]+4Ref.+4Play 4CH D1 IP Cameras
Audio Input 4CH network audio input
Video Output 1CH VGA + 1CH HDMI
Network Port 1 RJ45,10M/100M self-adaptive LAN port
USB Port 2 x USB 2.0 ports
HDD Port E-SATA/ Mobile HDD/ U-Disk
HDD Capacity Maximum 4TB HDD/ port
Mobile View Support (iPhone, Windows Mobile, BlackBerry, Symbian, Android) smartphones
Power Supply 5V2A
Working Temperature
-10°C - +55°C
Working Humidity 10%-90%
Dimension Equipment: 88mm×88mm×32mm
Weight (without HDD) N.W.: 105g; With packing: 250g
Installation Way Desktop Installation
*IPC stands for IP-Camera.
