Footswitch
Connect a single- or dual-button footswitch to iO Dock II to send CC Toggle messages that can be assigned in your
software. (Refer to your software's manual for more information on assigning these CC messages.)
Single-Button Footswitch:
If you are using a single-button footswitch, pressing the footswitch for the first time sends a data value of 127 for CC
#14 over Channel 1. Pressing the footswitch for the second time sends a data value of 0 for CC #14 over Channel 1.
Dual-Button Footswitch:
If you are using the first button of a dual-button footswitch, pressing the first button for the first time sends a value of
127 for CC #15 over Channel 1. Pressing the first button for the second time sends a value of 0 for CC #15 over
Channel 1.
If you are using the second button of a dual-button footswitch, pressing the second button for the first time sends a
value of 127 for CC #14 over Channel 1. Pressing the second button for the second time sends a value of 0 for CC
#14 over Channel 1.
