ELECTRIC SLIDING DOOR
01.17
O
R
I
G
I
N
A
L
PAGE 5
ESD 1106
VOLKSWAGEN T-5 from 2005 & T-6 from 2015
12
11
15
ENLARGE 6 HOLES
TO Ø14mm
13
AFTER FINISHING
THE OPENING
COVER WITH PAINT
TO PREVENT CORROSION
FINISH
OPENING
DRILL 2 HOLES
Ø6mm
Ø6
Ø10
ENLARGE FROM INSIDE
2 HOLES TO Ø10mm
