ALEXANDER ROSE 305 - Step 1 - Attach legs to seat support rails; Step 2 - Attach Cross rails to Cross rail centre plate

F
D
E
F
J x 4
Repeat this procedure with the other two sets of legs
A
K x 3
C
B
J x 12
I
(with pre-fitted thread inserts) using four long allen bolts, noting that the larger diameter holes in both
types of seat support rails face the outside as indicated.
DO NOT TIGHTEN BOLTS FULLY YET
Step 2 - Attach Cross rails to Cross rail centre plate
Attach left and right hand cross rails to the cross rail centre plate, using the long allen bolts
Step 1 - Attach legs to seat support rails
Attach the seat support rail (without pre-fitted thread inserts) to two seat legs and a seat support rail
Step 5 - Attach Table Top to Upper Legs
Attach the Table Top to the Upper Legs using Short Allen Bolts
