Connections in the pressure plate
It is important that the plate pack has been tightened to the correct dimension
A (check against the PHE drawing) before the piping system is connected.
When opening the heat exchanger, the pressure plate must be moved. Do not
use fixed pipes or other parts like feet, fasteners etc. inside the shaded area.
Drip tray (optional)
Depending on the type of fluid in the heat exchanger and the type of
installation, a drip tray (drainage box) may be necessary to avoid injury to
personnel and damage to equipment.
NOTE
Put the drip tray in place before positioning the heat exchanger.
200000547-4-EN-GB 21
Installation 4 EN
