4.4 Raising
This instruction is valid when raising the heat exchanger after delivery from Alfa Laval. Only use a
strap approved for the weight of the heat exchanger. Follow the principle of the instruction below.
CAUTION
The straps shall be long enough to be able to rotate the heat exchanger without obstruction.
Consider especially the space for the support column. Always be careful during the raising
procedure to avoid damage to the heat exchanger components.
1
Place two timber beams on the floor.
2
Lift the heat exchanger off the pallet using
e.g. straps.
3
Place the heat exchanger on the timber
beams.
4
Place straps around one bolt on each side.
200000547-4-EN-GB24
4 InstallationEN
