Operating Manual
11.0 Typical Sectional Arrangement
Item Description Qty
1 ‘O’ Ring Rotorcase 1
2 Stud Rotorcase Cover 3
3 Key, Rotor 2
4 Screw, Gearcase 4
5 Bearing Needle 2
6 Bearing, Needle Ring 2
7 Screw, Hammer Drive 2
8 Nameplate 1
9 Plug, Level 1
10 Plug, Filler 1
11 Shaft, Drive 1
12 Shim, Bearing 2 Packs
13 Screw, Gearcase Cover 4
14 Bearing, Duplex 2
15 Cover, Gearcase 1
16 Retainer, Bearing 2
17 Gear, Timing 2
18 Key, Gear 2
19 Lip Seal, Drive End 1
20 Rotor, Roloid Gear 2
21 Screw, Disc Retention 2
22 Disc, Rotor Retention 2
23 Nut, Closed 3
24 Cover, Rotorcase 1
25 Rotorcase 1
26 Dowel 2
27 Gland Packing 2 Packs
28 Gland Follower 2
29 Nut, Gland Stud 4
30 Lip Seal, Gland End 2
31 Stud Gland 4
32 Gearcase 1
33 Screw, Bearing Retainer 4
34 Sleeve, Timing Gear 2
35 Plug, Drain 1
36 Key, Drive 1
37 Shaft, Auxiliary 1
38 Nut, Bearing 4
