English

1 Components

Assembling your eleCtriCAl AlArm

Batteries Required: 2 X AA (not included)

 1. 1xSirenCover

2. 1 x Plastic Cone

 3. 1xLEDLight

 4. 1xSirenBody

5. 1 x Gear Cover

6. 1 x Motor

 7. 1xSwitchPlate

• OntheBasePlate(12),installtheSpringConnectors(11)atposition(3),(4),andwiththeSwitchPlate

(7)atposition(1)andMetalPlate(8)atposition(2)narrowenddown,pushthespringasfarasitwill

go.Makesuretheswitchisclosedbyitself.Connecttheredbatterywiretothespringconnectorat

position(1)andblackbatterywiretoposition(4)asshown(Fig.2).Bendthespringovertocreateagap

into which the metal wire is inserted.

• InstalltheResistor(10)byconnectingitswirestothespringconnectorsatposition(2)and(3)asshown

inFig.4.

• AsshowninFigure3,connecttheBuzzer(9)tothespringconnectorsasfollows:Buzzerredwire–2

 Buzzerblackwire–4

 8. 1xMetalPlate

 9. 1xBuzzer

10. 1xResistor

• AsshowninFig.5,installtheMotor(6)andLEDLight(3)totheSirenBody(4).Makesurethewiresgo

throughthecorrespondingholesatthebottom.

11. 4xSpringConnectors

12. 1xBasePlate

13. 1xPlasticTag

Colours and contents may vary

Alga Science ELECTROALARM User Manual
