3.3 RR2/ARC Connection -- Operation Description
Connection: Unplug the Y-axis motor wire from the Y-axis motor and
connect it to the corresponding motor jack of RR2/ARC.
Connect the control terminal: Use USB or other methods to connect
the computer.
LaserGRBL: Send "$22=0" in the “Type gcode here ”field.
LightBurn: Send the command "$22=0" in the "(Type Commands here)" field.
22
