Diagnostic Information
The DEVICE STATE screen displays live values for
the internal device registers. Many of these
values can help an Alicat applications engineer
diagnose operational issues over the phone.
Some register values clearly distinguish between
hardware and operational problems, which
speeds up the troubleshooting process.
Within the DEVICE STATE screen, press PAGE to
advance to the next page of register values.
Navigating and Customizing Your Flow Controller
About
We hope you don't run into trouble using your ow controller, but if you do,
the ABOUT menu contains information that can make the troubleshooting
process easier. Select MFG INFO to look up Alicat's phone number and web
address. DEVICE INFO shows you the serial number and rmware version (SW:) for
your specic device. It also gives you the original manufacturing date and the
last calibration date, as well as the initials of the Alicat calibraton technician.
Menu | About
MAIN
BACK
MFG
INFO
DEVICE
STATE
DEVICE
INFO
MAIN Exits to the Main Display
(page 19).
BACK Returns to the top-level
Menu (page 24).
DEVICE INFO Displays serial
number, rmware revision
and calibration information.
MFG INFO Displays Alicat's
contact information.
ALICAT SCIENTIFIC
www.alicat.com
Ph 520-290-6060
Fax 520-290-0109
MAIN
BACK
MODEL: MC-20SLPM-D
SERIAL NO: 182022
DATE MFG: 7/25/2018
DATE CAL: 7/25/2018
CAL BY: BP
SW: 7v22.0-R22
MAIN
BACK
DEVICE STATE Displays diagnostic
information for troubleshooting
(below).
MAINBACK
199
39414
37414
1034
9909
14810
39076
R10: DP Sig
R11: DP Brdg
R12: Vlv Drv
R13: AP Brdg
R16: MeterFunc
R9: Temp Sig
R8: AP Sig
PAGE
To Next Page
