Alicat MC Series User Manual

63
MNPT to Compression Fings
10-32 - 1/8” SS-200-1-0157
10-32 - 1/4” SS-400-1-0256
1/8” - 1/8” SS-200-1-2
1/8” - 1/4” SS-400-1-2
1/8” - 3/8” SS-600-1-2
1/8” - 1/2” SS-810-1-2
1/8” - 3mm SS-3M0-1-2
1/8” - 4mm SS-4M0-1-2
1/8” - 6mm SS-6M0-1-2
1/8” - 8mm SS-8M0-1-2
1/8” - 12mm SS-12M0-1-2
1/4” - 1/8” SS-200-1-4
1/4” - 1/4” SS-400-1-4
1/4” - 3/8” SS-600-1-4
1/4” - 1/2” SS-810-1-4
1/4” - 3mm SS-3M0-1-4
1/4” - 4mm SS-4M0-1-4
1/4” - 6mm SS-6M0-1-4
1/4” - 8mm SS-8M0-1-4
1/4” - 12mm SS-12M0-1-4
1/2” - 1/8” SS-200-1-8
1/2” - 1/4” SS-400-1-8
1/2” - 3/8” SS-600-1-8
1/2” - 1/2” SS-810-1-8
1/2” - 3/4” SS-1210-1-8
1/2” - 6mm SS-6M0-1-8
1/2” - 8mm SS-8M0-1-8
1/2” - 12mm SS-12M0-1-8
1/2” - 16mm SS-16M0-1-8
3/4” - 1/4” SS-400-1-12
3/4” - 1/2” SS-810-1-12
3/4” - 3/4” SS-1210-1-12
3/4” - 12mm SS-12M0-1-12
3/4” - 16mm SS-16M0-1-12
Filters & Elements FNPT-MNPT
10-32 5μ 510053
10-32 20μ 510054
1/8” 20μ ILF-1/8-20
1/4” 40μ ILF-1/4-40
1/2” 40μ ILF-1/2-40*
3/4” 40μ ILF-3/4-40*
20μ element ILFE20
40μ element ILFE40
40μ element ILFE40L*
Filters & Elements FNPT-FNPT*
10-32 5μ CF-303-20-316
*requires MNPT to MNPT coupler to
interface with Alicat ow bodies
10-32 Male UNF to 1/8 FNPT Adapter
410133
Male M5 (10-32) Buna-N O-ring face seal
to 1/8”Female NPT
Accessories
