4
Channel Instruction
Channel
Value
Description
CH1
064
Close light
64127
Auto-play
128-191
Sound active
192-255
Patterns control
CH2
0255
Choose patterns
CH3
0~63
Choose patterns size
64~127
From small to large,speed up rate
128-191
From large to small,speed up rate
192-255
Large small large, speed up rate
CH4
0~127
Choose rotation angle
128~191
Auto clockwise rotation, speed up rate
192~255
Auto anti-clockwise rotation, speed up rate
CH5
0~127
Choose horizontal position
128~255
Horizontal move,speed up rate
CH6
0~127
Choose Vertical position
128~255
Vertical move,speed up rate
CH7
0~127
Choose horizontal roll position
128~255
Horizontal roll ,speed up rate
CH8
0~127
Choose Vertical roll position
128~255
Vertical roll,speed up rate
Maintenance
Maintenance should be performed every 15-day period, by using a sponge
which is dipped with alcohol, rather than wet cloth or other chemical liquid, to
clean the mirror.
Always disconnect from the mains when the device is not in use or before
cleaning it.
Mode
Binary codeON
1
DMX-512 modeSlave mode
2
Sound active modeMaster mode
1-10:OFF
3
Auto play modeMaster mode
4
Square test pattern
5
Dot text pattern
