Align3GXV2.1‐SetupSummary
SwashplateSettings SpeedGovernorSettings RudderSettings FlightModeSetting
Setting6LED LED1~5alllitup
Setting Gyroinstallreversesetting
SetupMethod 1.Toachieveconsistentgyrogainonleftandright,3GXhas
builtinanti‐torquecompensationfunction.Userneedto
confirmif3GXismountedrightsideuporupsidedown.
2.Rightsideup:Installedwith3GX
labelfacingup,anti‐torque
compensationsettopositive(greenSTATUSLED).Upside
down:Installedwith3GXlabelfacingdown,anti‐torque
compensationsettonegative(redSTATUSLED).
4.Setupmethod:PressandholdtheSETbuttonfor2seconds
toentersetupmode,selectuntilanti‐torquecompensation
section,as
indicatedbylightingofall5setupmodeLEDs.Using
theruddersticktoselecteitherpositiveanti‐torque
compensation(greenSTATUSLED)forrightsideupmounting,
ornegativeanti‐torquecompensation(redSTATUSLED)for
upsidedowninstallation.
Inadditiontotransmitter,theanti‐torquecompensation
featurecanalsobe
setthrough3GXinterface'srudder
parameter.
Transmitter Setting RudderGainAdjustmentonTransmitter
SetupMethod 1.Forradiowithbuiltingyrogainsettings,gaincanbeadjusted
directly.Forexample,50%‐100%settingontheradio
translatesto0%‐100%gainintheheadinglockmode;50%‐0%
settingontheradiotranslates
to0%‐100%gaininthenormal
(non‐heading)lockmode.
2.Actualgainvaluediffersamongstservosandhelicopters.
Thegoalistofindthemaximumgainwithouttailhunting.This
canonlybedonethroughactualflighttests.
3.Therecommendedstartingpointfortransmitter'sgyrogain
settingshouldbe
70~80%forhovering,60~70%foridle‐up.
Valueshouldbetunedunderactualflightconditionsby
increasingtothemaximumgainwithouttailhunting.
Warnings Aftercompletingsettingof8degreesSWASH,do
notmakefurtheradjustments.Ifadjustmentto
helicopter’srollrateisneeded,theadjustment
mustbemadeinthe
rollrateunderflightmode’s
cyclicpitchsection.
1.FlashingLEDindicates10%;fullylitLEDindicates20%.For
example,LED1andLED2arefullylit,whileLED3isflashing,thisis
translatedto2*20+10=50%.
2.Movethesticktodisplaythestickfunction’ssettingvalue.For
example,movingaileronstick
willresultinLED1~LED5displaying
aileron’ssettingvalue.
DeonduRand‐2012‐7‐04
3GXV2.1EasySetupTable(English).xlsx DduRand‐July2012 4of4
