Reference Guide V1.5.0
• Adjust parameters by touching to select and then using the touchscreen rotary.
Gate threshold also has a dedicated rotary.
Attack = 50µs to 300ms
Hold = 10ms to 5secs
Release= 10ms to 1sec
Threshold = -72dB to +18dB
Depth = 0dB to 60dB
Histogram –
The histogram shows the previous 12 seconds of gate activity, moving from right to
left. As with the reduction meter, when the gate is in, the level reduction (depth) is
shown in red, and when out is shown in white/grey.

ALLEN & HEATH SQ-7 Specifications

General

MIDI out	Yes
RJ-45 ports quantity	1
Channels quantity	48 channels
Supported sample rates	96 kHz
Digital sound processing	- bit
DJ mixer	-
Product color	Black
Power consumption (typical)	- W

Weight and Dimensions

Depth	514.9 mm
Width	804 mm
Height	198 mm
Weight	17800 g
Package depth	685 mm
Package width	960 mm
Package height	360 mm
Package weight	21900 g
