8
CC
FF
ASSEMBLY INSTRUCTIONS
Hardware Used
Hardware Used
Hardware Used
1. Install the glass shelves (E) to the desired positions
with shelf clips (BB), making sure they are level.
2. Use the shelf hole plugs (CC) to seal the empty
holes.
3. Stick the bumpers (FF) at the two corners of the
door
(D) opposite the door hinges (A).
1
2
3
Shelf Clip
Shelf Hole Plug
Bumper
x 12
x 20
x 2
BB
CC
FF
E
BB
Note: These steps are applicable to both surface-mount installations and recess-mount installations.
Lowes.com/allenandroth
