Page 4
www.allfett.net
GENERAL DIMENSIONS
Technical drawings below represents the ALL-6 pump. Dimension unit is milimeter.
115mm
Ø8
285mm
Ø69mm
75mm
135mm
Assembly holes
158mm
Ø6
