AllFitHD AF-4222LS - Page 11

47
47
48
49
36
19
19
51
40
Insert Connecting Tubes (36) into Hitch Mount Tubes (19) and secure with
Quick-Release Pins (47).
Install Hitch Pin (49) and secure with Hairpin (48).
Tie Dump Rope (51) securely around exposed section of Center Frame Tube (40).
Do NOT fasten rope to any
part of your body or clothing.
10
Assembly Instructions
15
16
