12
Operating Instructions
Periodic Maintenance:
Tighten fasteners as needed before each use
•
Empty hopper and thoroughly clean Lawn Sweeper after each use
•
Remove any materials that have wrapped around brushes or brush shaft
•
after each use
Lubricate wheel bearings and gears annually with a light coating of white
•
lithium grease
Storing Lawn Sweeper:
Empty hopper bag and thoroughly clean Lawn Sweeper before storing.
1.
Store Lawn Sweeper away from excessive heat to prevent damage.
2.
Brushes must not contact ground during storage to prevent damage.
3.
Remove quick-release pins to separate hopper bag from Lawn Sweeper.
4.
Carefully remove tension tube and collapse hopper bag for compact storage.
5.
Unpin and detach adjustment lever from handle and then depress snap
6.
buttons to remove hitch tubes from Lawn Sweeper for compact storage.
4 5
6
