Chapter 1: AlliedWare Plus Command Line Interface
54
Figure 8. INTERFACE PORT Command - Multiple Ports
The INTERFACE PORT command is also located in the Port Interface
mode itself, so that you do not have to return to the Global Configuration
mode to configure different ports. This example moves from the current
Port Interface mode to the Port Interface mode for ports 7 and 10.
Figure 9. INTERFACE PORT Command - Moving Between Port Interface
Modes
INTERFACE
Command -
Static Port Trunk
You use this command to move from the Global Configuration mode to the
Static Port Trunk Interface mode, to change the load distribution methods
of static port trunks. You specify a trunk by its name of “sa” followed by its
ID number. You can specify only one static port trunk at a time. The format
of the command is:
interface
trunk_name
This example enters the Static Port Trunk Interface mode for trunk ID 2:
Figure 10. INTERFACE TRUNK Command
INTERFACE
VLAN Command
You use this command to move from the Global Configuration mode to the
VLAN Interface mode to assign the switch a management IP address. The
format of the command is:
interface vlan
vid
The VID parameter is the ID of an existing VLAN on the switch. This
example enters the VLAN Interface mode for a VLAN that has the VID 12:
Figure 11. INTERFACE VLAN Command
awplus(config)# interface port1.0.11-port1.0.15,port1.0.22
awplus(config-if)#
awplus(config-if)# interface port1.0.7,port1.0.10
awplus(config-if)#
awplus(config)# interface sa2
awplus(config-if)#
awplus(config)# interface vlan12
awplus(config-if)#
