Allied Telesis AT-GS900M Series User Manual

Chapter 14: Switching Commands
274 Section III: Layer 2 Switching
SHOW SWITCH PORT COUNTER
Syntax
show switch port[= port_list |all] counter
Parameters
port_list
Specifies a list of ports. To specify multiple ports, use a comma (,)
to separate them. To specify a range of ports, use a hyphen (-).
all
Specifies all the switch ports.
Description
Use this command to display statistics counters on ports. An example of
the command output is shown in Figure 40.
Figure 40. SHOW SWITCH PORT COUNTER Command
Switch Port Counters
-------------------------------------------------------------------------
Port 1. Counters:
Combined receive/transmit packets counters:
64 : 1757 1024-1518 : 0
65-127 : 314 1519-1522(T) : 0
128-255 : 485 1519-2047 : 0
256-511 : 113 2048-4095 : 0
512-1023 : 0 4096-9216 : 2503749
General Counters:
Receive Transmit
Octets : 21341360956 Octets : 0
UnicastPkts : 1 UnicastPkts : 0
MulticastPkts: 12 MulticastPkts: 0
BroadcastPkts: 2656 BroadcastPkts: 0
Discards : 2506241 Discards : 0
Errors : 13839360 Errors : 0
PauseFrames : 0 PauseFrames : 0
AlignmentErrors : 0
FCSErrors : 0
LateCollisions : 0
ExcessiveCollisions : 0
CarrierSenseErrors : 0
FrameTooLongs : 0
SymbolErrors : 0
UndersizePkts : 13839360
Fragments : 0
Jabbers : 0
SingleCollisionFrames : 0
MultipleCollisionFrames: 0
DeferredTransmissions : 0
