Typical 3000 MH Series Transmission
OUTPUT
SPEED
SENSOR
NAMEPLATE
INPUT
SPEED
SENSOR
ASSEMBLY PADS
MAIN-PRESSURE TAP
NOTE: Inch Series Threads
BREATHER
FEEDTHROUGH HARNESS
CONNECTOR
COOLER PORTS
NOTE: Inch Series Threads
V06341
ASSEMBLY PADS
(BOTH SIDES)
BREATHER
MAIN-PRESSURE TAP
NOTE: Inch Series Threads
FEEDTHROUGH HARNESS
CONNECTOR
TORQUE CONVERTER
WITH LOCKUP CLUTCH
AND TORSIONAL DAMPER
FILL TUBE AND DIPSTICK
(Available on both sides)
