Specification
Items Description
Line Rate
56Mbps
Effect Data Rate
Up to 16Mbps effective throughput
Frequency Band
4.3~20.9 MHz
Access Methods
CSMA/CA
Qos
4 Levels
Modulation
OFDM (QAM 64/16, DBPSK, DQPSK)
Port
One Ethernet port
Standards
IEEE 802.3, IEEE 802.3U, HomePlug 1.0.1
Operating System
Window 98 SE, Me, 2000,XP, MAC, Linux
Nodes
Supports up to 15 nodes per network
Encryption
56 bit DES Link Encryption with key management
LEDs
Red(Up) : PowerLine Collision
Yellow : PowerLine Activity
Green : PowerLine Link
Yellow (Down) : Ethernet Link
Operating : 0~40°C Temperature
Storage : -20~60°C
Operating : 10~85% Non-Condensing
Environment
Relative
Humidity
Storage : 5~90% Non-Condensing
Power Source
100~240 VAC, 50/60 Hz
Certification
FCC, UL, CE, HomePlug 1.0.1
LEDs
LINK/ACT On: 100M Ethernet device detected
Off: 10M/No Ethernet device detected
Blinking: Ethernet traffic detected
LINK On: PowerLine adapter detected
Off: No PowerLine adapter detected
ACT Blinking: PowerLine traffic detected
Off: No PowerLine traffic detected
COL Blinking: PowerLine collision detected
Off: No PowerLine collision detected
ALL1693 © 2005 All rights reserved. Page 7
