Replacing the UV Bulb
NEVER look directly at the UV light.
When replacing your UV bulb, use this time to clean your quartz sleeve and
carefully examine for any damage or cracks. Take care when handling the
quartz sleeve and UV bulb to avoid any damage to the glass.
1. To access UV bulb unfasten the clip located on the side (CUV-207 / 209 and
211 models only) or using a coin push down the
clear plastic button on top of the ballast (CUV-218 /
224 / 236 / 272 models only). Gently turn the ballast
counter clockwise and pull the ballast apart from
the UV case.
IMPORTANT! The replacement does not require
removal of the gold outer shell protecting the
bulb (CUV-207 / 209 and 211 models only).
The top of the gold outer shell has sharp edge, DO
NOT touch this part.
2. Once cooled, UV bulb can be safely removed by
gently moving it from side to side (CUV-207 / 209 /
211) and pulling free of unit.
3. You can now replace your UV bulb and
reassemble the unit. Ensure O-rings are
replaced when reassembling to avoid water
ingress.
CUV-218 / 224 / 236 / 272 - when taking your
quartz sleeve out, you might notice the orange O-
ring falls out into the ballast part of the unit. When
reassembling your unit make to replce it as seen in
the image on the right. This is to enable you to
correctly close the unit.
CUV-218 / 224 / 236 / 272
CUV-207 / 209 / 211
