PARTS DIAGRAM
CUV-218 / 224 / 236
O RING 2
O RING 1
SCREWS
UV BALLAST
O RING 3
UV BULB
1
2
3
4
5
6
QUARTZ SLEEVE
7
CLAMP SCREW
8
1
2
3
4
5
6
7
9
10
11
12
13
14
15
8
5
O RING 4
9
10
HELIX
10
FILTER BOTTOM
11
NUT
11
12
CUV BODY
12
FIXING BRACKETS
HOSETAIL O-RING
13
14
15
HOSETAIL OUTLET
16
UV VIEWING GLASS
16
