Allsource 42000 - Parts List - Section 1

23
42000
Operating Instructions and Parts Manual
High Pressure Abrasive Blast Cabinet
Item No.
Part No.
Description
Qty.
1
Cabinet Assembly
1
2
Grid
2
3
Bolt M6x16
22
(matched with φ6*16 washers)
4
41825
PSA foam
1
5
Bracket
1
6
Cover grid
1
7
Funnel
1
8
Rear Bar
1
9
Left Bar
1
10
Bolt M6*12
24
11
42011
Control Panel
1
12
42012
Tank Assembly
1
13
Right Bar
1
14
Bolt M8*20
32
15
42015
Leg
4
16
Leg Reinforcements
2
17
Leg Reinforcements
2
18
Stand
1
19
42019
Foot Pedal
1
20
4150063
Dust Collector
2
21
Bolt M6*32
12
22
41821
Window Frame
1
23
41822
Window lens outer
1
24
41823
Window lens inner
1
25
41824 or 41915(5pk)
Window Underlay
1
26
41825
PSA foam of Viewing Window
1
27
41826
Rubber Door Seal
1
28
42028
Lamp Housing
1
29
42029
LED Light
3
30
42030
Light lens
1
31
42031
Light lens underlay
2
32
42032
Rubber seal of light lens
1
33
Cover plate
2
34
41834
Main Support Pole
2
35
41835
Air Spring Support Rod
2
36
42036
Plastic Slot
1
37
42037
Switch Box
1
38
41837
Front Door Latch
2
39
41838
Latch Seat
2
