Magnetic Strip Installation
1) Center the Mesh (D) and allow a 1 in overlap
on all 4 corners. Press the 3 Mesh Place Holders
(F) onto the Groove Magnet Strips (B) to help
hold the Mesh (D) in place.
2) Apply the White Molding Strip (C) over the
Groove Magnet Strip (B). Please note to
remove the Mesh Place holder (F) when you
get to its location.
1) Apply all Corner Moldings (G) to all four corners
of the frame.
At this stage, the window screen is now removable.
2) Remove the backing from the Wind Clip (E) and pull the
upper righthand corner of the screen. Press down on the
Wind Clip (E) onto the magnet Strip (A). Slide the window
screen into the groove of the Wind Clip(E).
Repeat these steps to the upper lefthand corner.
Corner & Wind Clip Installation
3
Screen Installation
