Allwinner T527 - Page 2

A A
B B
C C
D D
1
1
2
2
3
3
4
4
5
5
TITLE:
REV:
Date:
Sheet:
Drawn By:
Company:
Total:
YuzukiHD
1.0
2 13
2024-08-30 GloomyGhost
Avaota A1 八核 AIoT 开发板
5
4
3
2
1
DC1
DC-044A-A200
U1
100uF
U2
100uF
D2
SMCJ15CA
Q1 YJL2305A
R1
100K
R2
100K
GNDGND
C3
100nF
GND GND
C1
100nF
C2
100nF
DCIN-12V
BOOT
1
VIN
2
EN
3
SS
4
VSENSE
5
COMP
6
GND
7
PH
8
EP
9
U3
TPS54531DDAR
C4
100nF
C7
100nF
L1
4.7uH
R4
665K
R6
130K
GND GND
DCIN-12V
C8
100nF
GND
D4
SS54
GND
C9
2200pF
C10
22pF
R7
37.4K
C5
47uF
C6
47uF
DCIN-5V
R3
51.1
R5
10.2K
R8
1.96K
GND
D3
SS54
VBUS
D1
B5819WS
GND GND
GND
VBUS
1
1
2
2
34
CN4
0533980271
