B. Installation using a generic external metal U-bracket on a U-clamp that can be
attached around a tube-shape surface:
Torque on screws regarding plastic mounting bracket. The maximum torque of the mounting plate
must not be exceeded 1 Nm (0.73 ft lb).
This method ensures good, non-intrusive fixation of the Aloxy Pulse to an asset suitable for instance
for movement detection and vibration monitoring. Typical applications are manual valve position
monitoring by attachment to a valve lever or a spoke or outer ring of the valve wheel, vibration
monitoring of a tube, etc.
C. Installation using M5 bolts or screws on a flat surface:
NOTICE
Torque on screws regarding plastic mounting bracket. The maximum torque of the mounting plate
must not be exceeded 1 Nm (0.73 ft lb).
