_Aloxy Pulse
Instruction
Manual
EN
28
34
LoRaWAN EU Labo De Nayer
PCC-RAD-4918_ed2
PCC-RAD-5034_ed2
USA
Certification
ongoing
Canada
Certification
ongoing
DASH7
EU
Self
-
certification based on
D7A v1.2 towards
reference stack
implementation
USA Certification ongoing
Canada
Certification o
n
going
Compliant Reference
WEEE 2011/65/EU
RoHAS
2012/19/EU
Enclosure
Reference
Mounting
position
Horizontal or vertical NA
Demensions L x H x W 88,5 x 50,3 x 41,2 mm NA
Weight
With PCB and power supply
approx. 150gr (5.3oz)
NA
Battery approx. 50gr (1.8oz) NA
Lithium content 2,2 gr
(0.078oz)
NA
Materials
Top shell
Softpart
yellow
TPE yellow (conductivity 285Mohm)
Kraiburg HTC8797/137
Softpart
black
Nylabond TE ESD RTP C146255B1Black
Hard part Nylon PA6 natural SOLVAY Technyl C206F
Bottom shell
Nylon 6 ESD
protection black
RTP0299AX123289BLACK
Mounting plate
