Communication
range
LoRaWAN SF7 500m SF and distance to the
gateways has a
profond inpact on the
battery life.
SF9
1 km
SF12 <2 km
Frequency
DASH7
-
EU
863
-
870MHz
NA
LoRaWAN - EU 867-870 MHz NA
DASH7
-
USA
902
-
928MHz
NA
LoRaWAN
-
USA
902
-
928MHz
NA
Payload
DASH7
max 251 bytes
NA
LoRaWAN
max 243 bytes depending on SF
NA
Latency Dash7 max 1 sec NA
LoRaWAN
up to 4 min
NA
EMC
Compliance
Europe
LDN: PCC
-
EMC
-
5002
LDN: PCC-RAD-4918
Rated condition
Reference
Ambient conditions
For use indoors and outdoors.
NA
Ambient temperature In hazardous areas, observe the maximum
permissible
ambient temperature corresponding to the
temperature
class.
NA
Permissible ambient temperature for operation Permissible ambient temperature for operation -40
to +70 °C (-40 ... +112 °F)
NA
Relative humidity 0 ... 100% NA
IEC 61010 Compliance
Meets Pollution Degree
3
NA
Altitude Rating Up to 2000 meters (6562 feet) NA
Operating Temperature Limits
Battery Power:
-
40°C
≤ Ta ≤ +70°C (
-
40 to 158°F)
NA
Vibration
resistance
Harmonic oscillations (sine) according to EN
60068-2-6/10.2008
3.5 mm (0.14"), 2 ... 27 Hz, 3 cycles/axle
98.1 m/s² (321.84 ft/s²), 27 ... 300 Hz, 3 cycles/axle
Pending for evaluation
