SPECIFICATIONS
Model RCM 2000 EIT
Voltage 220 – 240 V – 50 Hz
Maximum Power 2000 W
Class II
USING
This appliance has been designed for wall mounting only. Do not use it in another position.
SECURITY DISTANCE TO BE RESPECTED :
- Mark the place of the 2 screws on the wall (distance of 470 mm between) (Fig. 2).
- Use a level to check the horizontally of the heater.
- Drill the holes, insert screw anchors and put the two screws inside.
- Place the appliance in front of the screws, and put them inside the mounting holes of the support
(L shaped).
- Move the appliance to the right and downwards to fix it.
- Use the most convenient pre-cut cord ‘knock out’ to pass the power cord.
9
Fig. 2
