Never allow the battery pack to discharge
completely. This will result in damage to the NiMH
battery pack!
Adjusting the torque (1)
The battery-powered drill/screwdriver is equipped
with a 22-step mechanical torque adjustment facility.
The torque for a specific size of screw is selected
with the set-collar (Figure 1). The correct torque
depends on several factors:
앬 on the type and hardness of material in question
앬 on the type and length screws used
앬 on the requirements needing to be met by the
screwed joint.
The clutch disengages with a grating sound to
indicate when the set torque is reached.
Important! The tool must be at a standstill when
you set the torque with the setting ring.
Drilling
For drilling purposes, move the set-collar to the last
step „Drill“. In this setting the slip clutch is inactive.
The maximum torque is available in drilling mode.
Forward/Reverse switch (3)
With the slide switch above the On/Off switch you
can select the direction of rotation of the battery-
powered drill/screwdriver and secure it against being
switched on accidentally. You can choose between
clockwise and anticlockwise rotation. To avoid
causing damage to the gearing it is advisable to
change the direction of rotation only when the tool is
at a standstill. The On/Off switch is blocked when the
slide switch is in centre position.
On/Off switch (4)
Infinitely variable speed control is possible with the
On/Off switch. The further you press the switch, the
higher the speed of the battery-powered
drill/screwdriver.
Changing over from 1st gear to 2nd
gear (7)
You can work at a higher or lower speed depending
on the position of the selector switch. To avoid
damaging the gear unit you should only change over
gears when the tool has stopped.
Screwdriving
We recommend using self-centering screws (e.g.
Torx screws, recessed head screws) designed for
reliable working. Be sure to use a bit that matches
the screw in shape and size. Set the torque, as
described elsewhere in these operating instructions,
to suit the size of screw.
6. Technical data
Voltage supply 12 V d.c.
Speed 0-350/0-1100 rpm
Torque 22 levels
Forward and reverse rotation yes
Chuck clamping width 1,0 - 10 mm
Battery charging voltage 12 V d.c.
Battery charging current 2,5 A
Mains voltage for charger 230 V ~ 50 Hz
Weight 1.47 kg
Sound and vibration
Sound and vibration values were measured in
accordance with EN 60745.
L
pA
sound pressure level 70 dB(A)
K
pA
uncertainty 3 dB
L
WA
sound power level 81 dB(A)
K
WA
uncertainty 3 dB
Wear ear-muffs.
The impact of noise can cause damage to hearing.
Total vibration values (vector sum of three directions)
determined in accordance with EN 60745.
1. Drilling in concrete
Vibration emission value a
h
= 1,259 m/s
2
K uncertainty = 1,5 m/s
2
2. Screwing without hammer action
Vibration emission value a
h
= 0,610 m/s
2
K uncertainty = 1,5 m/s
2
Important!
The vibration value changes according to the area of
application of the electric tool and may exceed the
specified value in exceptional circumstances.
9
GB
