It is imperative to observe the manufacturer’s
safety, operating and maintenance instructions
as well as the dimensions quoted in the
technical data.
It is imperative to observe the accident
prevention regulations in force in your area as
well as all other generally recognized rules of
safety.
Note the information published by your
professional associations (VBG 7j).
Switch on the dust extraction system each time
you use the machine.
Use the saw only with a suitable vacuum
extraction system or a standard industrial
vacuum cleaner in order to prevent injuries
caused by flying pieces of wood.
Wear goggles
Wear ear-muffs
Wear a breathing mask
Noise emission values
The saw’s noise is measured in accordance with
DIN EN ISO 3744; 11/95, E DIN EN 31201;
6/93,ISO 7960 Annex A; 2/95. The noise may
exceed 85 dB(A) at the workplace. In this case,
noise protection measures need to be
introduced for the user (ear-muffs).
Cutting Idling
Sound pressure level LPA 90 dB(A) 68 dB(A)
Sound power level LWA 99 dB(A) 82 dB(A)
„The quoted values are emission values and not
necessarily reliable workplace values. Although there
is a correlation between emission and immission
levels it is impossible to draw any certain conclusions
as to the need for additional precautions. Factors
with a potential influence on the actual immission
level at the workplace include the duration of impact,
the type of room, and other sources of noise etc.,
e.g. the number of machines and other neighbouring
operations. Reliable workplace values may also vary
from country to country. With this information the
user should at least be able to make a better
assessment of the dangers and risks involved.“
5. Technical data
Asynchronous motor 230 V 50 Hz
Power rating 600 W
Temporary operation S3 50%
Idle speed n0 2800 rpm
Carbide saw blade 200 x 16 x 2.8 mm
Number of teeth 24
Table size 500 x 335 mm
Cutting height max. 43 mm / 90°
26 mm / 45°
Table tilt infinite 0 - 45°
Connector for dust extractor dia. 34 mm
Size, complete 500 x 335 x 265 mm
Packaging 560 x 360 x 290 mm
Weight 11 kg
6. Before putting the machine into
operation
The machine has to be set up where it can stand
firmly, e.g. on a work bench, or it must be bolted
to a strong stand.
All the covers and safety devices have to be
properly fitted before the machine is switched on.
It must be possible for the saw blade to run
freely.
When working with wood that has been
processed before, watch out for foreign bodies
such as nails or screws etc.
Before you actuate the On/Off switch, make sure
that the saw blade is correctly fitted and that the
machine’s moving parts run smoothly.
Before you connect the machine to the power
supply, make sure the data on the rating plate is
the same as that for your mains.
GB
13
