9 Running the OPC R1 using direct SPI control
Full details of the SPI commands and connections are available for the OPC-R1. This is should be
sufficient for the user to be able to design their own SPI system to control the device and gather
data.
A flow chart outlining simple operation of the OPC R1 is given in 072-0501 Supplemental SPI
information for OPC-R1.
The R1 has a very low power off state unlike the OPC-N2, if the unit is placed into the low power
mode we recommend that the fan and laser are powered up for a minimum of 10 s before taking a
measurement.
10 Revision Control
