Alphasonik HYPER 200 Series - Subwoofer Parameters

SUBWOOFER PARAMETERS
9
HYPER SERIES
Model # HSW208 HSW210 HSW212
Fs 47 35 34
Qts 0.488 0.512 0.572
Qes 0.529 0.558 0.643
Qms 6.34 6.23 5.18
Vas (liters) 11.31 33.57 69.08
Vas (Cu. Ft.) 0.399 1.19 2.43
Re 3.33 3.58 3.55
Rms 2.725 3.346 4.479
Xmax +/- (mm)
Le 1.189 1.554 1.657
Sd 201.06 330.06 490.87
SPL 86 87 88.74
EBP 88 68 52
Mmd 56 88 97
Freq. Resp. 35Hz-500Hz 30Hz-500Hz 25Hz-500Hz
Mounting Dimensions
Depth (mm) 94mm 118mm 128mm
Depth (Inches) 3.7" 4.65" 5.04"
Through Hole (mm) 184mm 233mm 278mm
Through Hole (Inches) 7.24" 9.17" 10.94"
Diameter (mm) 220mm 270mm 318mm
Diameter (Inches) 8.66" 10.63" 12.52"
Displacement .057 Cu.Ft. .10 Cu.Ft. .14 Cu.Ft.
Sealed Enclosures
Minimum Sealed 0.5 cu. ft. 0.75 cu. ft 1 cu. ft.
Maximum Sealed 0.85 cu. ft. 1.55 cu. ft. 2.86 cu. ft.
Vented Enclosures
Minimum Vented 1 1.25 2
Internal Volume 0.94 1.2 1.67
Port Dia/Inches 3" 3" 2x4"
Port Length/Inches 8 7.75" 12..75"
(-3dB) 38 33 42
Tuning Freq. 45 40 50
Port Displacement 0.032 0.031 0.185
Maximum Vented 2 1.75 3.5
Internal Volume 1.92 1.62 3.14
Port Dia/Inches 3 4" 2x4"
Port Length/Inches 9" 14" 14.25"
(-3dB) 27 29 30
Tuning Freq. 30 30 35
Port Displacement 0.036 0.101 0.207
Rev 18.12
