Drawing⑤
1.The left big roof:: Put the long and short crossband with left following
crossband A to the neck in the middle board and left backbone A. Them lock
them by screw CT-M5*50.
2.The right big roof: Put the long and short crossband with left following
crossband B to the neck in the middle board and left backbone B. Them lock
them by screw CT-M5*50.
3.Attention please when fit, after 3pcs crossband are put in the neck, you
should make flat the contact surface of backbone and middle board, and then
lock them by screw.
Keep the contact surface flat
The left crossband A
The left backbone A
The sink hole
is at the above
Screw CT-M5*50
The left big roof
A
The right big roof
The right backbone B
The sink hole
is at the above
The right following crossband B
B
To Next Page
