Alpine CDE-9841 - IC101 Terminal Descriptions (Part 3); IC101 Terminal Details (cont.)

CDE-9841/CDE-9841E
No. Symbol I/O Terminal Description
93 STS O Status output terminal.
94 SCK I Serial clock input terminal.
95 TEMP I Temperature detect terminal.
96 VREF+ - Power supply terminal for A/D converter.
97 OUTR O Rch audio output terminal.
98 AVDD1 -
Power supply terminal for analog circuit.
(for audio output block (for using both as Lch and Rch))
99 OUTL O Lch audio output terminal.
100 AVSS1 -
GND connect terminal for analog circuit.
(for audio output block (for using both as Lch and Rch))
- 30 -
