35-EN
ALPINE CDE-170E 68-40368Z02-A (EN) 128x182
and the
rotection
nit.
on collar
they
, then
Mounting the unit in the dashboard
• Before installing, make sure the catches on
both sides of the bracket
are bent inwards
2mm (/ in).
• For Japanese cars, see ”Mounting the unit in a
Japanese car” (page 35).
1 Position the bracket inside the
dashboard, then bend the claws outward
for a tight fit.
53 mm (2 / in)
Catch
182 mm (7 / in)
2 Mount the unit onto the bracket , then
attach the protection collar
.
Notes
• If the catches are straight or bent outwards, the unit will
not be installed securely and may spring out.
• Make sure the 4 catches on the protection collar
are
properly engaged in the slots of the unit.
Mounting the unit in a Japanese car
You may not be able to install this unit in some
makes of Japanese cars. In such a case, consult
your Alpine dealer.
TOYOTA
to dashboard/center console
Bracket
Bracket
Existing parts supplied
with your car
NISSAN
to dashboard/center console
Bracket
Bracket
Existing parts supplied
with your car
Note
To prevent malfunction, install only with the supplied
screws
.
Detaching and attaching the front
panel
For details, see “Detaching the Front Panel”
(page8).
Resetting the unit
For details, see “Resetting the Unit” (page8).
