Specifications
Model: AP6-Pro
Dimensions
190mm (7.5") x 125mm (4.9")
32mm (1.25")
Weight 0.4 kg (0.9 lbs)
Mount Material
Ceiling/Wall: Polycarbonate
Drop Ceiling: Steel
Weatherproofing IP54
Network Interface Ethernet, WiFi, Bluetooth
Management Interface (1) GbE RJ45 Port
Button(s) Reset/Factory Reset
LED Blue, White
Power Method PoE+
Power Supply
PoE+ Enabled Network Switch
48V, 0.5A PoE Adapter
(Optional)
Supported Voltage Range 42.5-57V DC
Max. Power Consumption 25W
Max. Transmit Power
2.4 GHz: 23 dBm @2NSS
5 GHz: 26 dBm @4NSS
MIMO
2.4 GHz: 2 x 2
5 GHz: 4 x 4
Throughput Rate
2.4 GHz: Up to 573 Mbps
5 GHz: Up to 5.8 Gbps
Mounting
Wall, ceiling, drop-ceiling,
table top
Operating Temperature -30 to 60° C (-22 to 140° F)
Operating Humidity 5 to 95% Noncondensing
Certifications CE, FCC, IC
