Fig. 1 - ReServ1
P
N
LOW BATTERY
SHUTDOWN
Input
--- 24VDC +
9 10 11 12 13 14 15 16 1 2 3 4 5 6 7 8
Green
Lead
12VDC Rechargeable Battery
(order separately)
12VDC Rechargeable Battery
(order separately)
Supervised - Non power-limited
CAUTION: Risk of explosion if battery is replaced by an incorrect type.
Dispose of used batteires according to the instructions.
Non power-limited
5A
250V
Unswitched
115VAC
60Hz, 3.5A
power mains
(non power-limited)
24VAC
Power-Limited Outputs
12VDC
Power-
Limited
Outputs
Note: Two (2) 12VDC rechargeable batteries connected in series required.
power-
limited
AC
DC
To Next Page
