Altronix ReServ1 User Manual

ReServ1 - 3-
Stand-by Specifications:
Terminal Identifications:
OLS120 Power Supply/Charger Board
ReServ1B Circuit Board
LED Diagnostics:
OLS120 Power Supply/Charger Board
ReServ1B Circuit Board
Stand-by Battery 4 amp (100VA) Load at 24VAC and/or 12VDC max.
2 - 12VDC/7AH 45 minutes
2 - 12VDC/12AH 90 minutes
Terminal Legend Function/Description
L, G, N Connect 115VAC to these terminals: L to Hot, N to Neutral, G to ground (if used).
+ DC --- 24VDC @ 4 amp continuous output.
AC Fail
NO, C, NC
Used to notify loss of AC power, e.g. connect to audible device or alarm panel. Relay normally
energized when AC power is present. Contact rating 1 amp @ 28VDC.
Low Battery
NO, C, NC
Used to indicate low battery condition, e.g. connect to alarm panel. NO, C, NC Relay normally
energized when DC power is present. Contact rating 1 amp @ 28VDC.
Low battery threshold:
24VDC output threshold set @ approximately 21VDC.
--- B A T + Stand-by battery connections. Maximum charge rate .5 amp.
Terminal Legend Function/Description
Input + --- 24VDC from OLS120 power supply/charger.
24VAC - N, P 1-8 24VAC outputs.
12VDC - + 1 -- to + 4 -- 12VDC outputs.
Red (DC) Green (AC) Power Supply Status
ON ON Normal operating condition.
ON OFF Loss of AC, Stand-by battery is supplying power.
OFF ON No DC output.
OFF OFF Loss of AC. Discharged or no stand-by battery. No DC output.
LED LED State Description
24VAC Output
1-8
ON Normal operating condition.
OFF Loss of output power.
12VDC Output
1-4
ON Normal operating condition.
OFF Loss of output power.
Low Voltage
Input
ON Voltage input is low.
OFF Normal operating condition.
Shutdown
ON No Power. Batteries are discharged.
OFF Normal operating condition.
