- 16 -
Instruction for montage of outside roller shutters in
ADAPTING system, type SK
and in
ADAPTING system, type SK with MOSKITO.
SK_+_moskito_m_uk
We reserve the right to any technical change. Valid on: 2009-06-02
87
88
89
90
91
92
93
94
k) Close the mosquito net in such position which seal up the space between the endslat and window frame by the (side)
brush [87]. Then (at the opposite side of the window) mark the position of mosquito net’s endslat. [88]. Adjust the side
lock’s nest to an appropriate height (in each guide channel) and then screw tightly with suitable strength [89], [90].
Lower the mosquito net and check, if the surface between endslat and window frame is sealed up by the brush [91].
l) Remove the protective foil from the box [92] and guide channels [93] and from the other elements. Cover the holes in the
guide channels [94].
m) Train the user in the scope of roller shutter’s operating.
n) Pass to the user the instruction of operating and maintenance, warranty and sign the protocol of receipt.
