Amana ASXC16 User Manual

SERVICING
72













  
• Air conditioner/heat
pump fails to operate
• Integrated control
module diagnostic/
status LED display
shows the indicated
code
BLANK d 0 • Data not yet
on Network
• Air conditioner/
heat pump is
wired as part of
a communicating
system and
integrated control
module does not
contain any shared
data
• Verify system type
(communicating or
legacy)
• Populate shared
data using Bluetooth
®
Shared Data Loader
BTSDL01
• Wire system as
legacy system
• Turn power OFF
prior to repair
• Use Bluetooth
®
Shared Data Loader
BTSDL01 for your
specic model
• Insert Bluetooth
®
Shared Data Loader
BTSDL01 BEFORE
turning power ON.
Bluetooth
®
Shared
Data Loader
BTSDL01 may be
removed after data
is loaded. Turn
power OFF before
removing Bluetooth
®
Shared Data Loader
BTSDL01
• Air conditioner/heat
pump fails to operate
• Integrated control
module diagnostic/
status LED display
shows the indicated
code
BLANK d 1 • Invalid Data
on Network
• Air conditioner/
heat pump is
wired as part of
a communicating
system and
integrated control
module contains
invalid shared data
or network data
is invalid for the
integrated control
module.
• Verify system type
(communicating or
legacy)
• Populate correct
shared data using
Bluetooth
®
Shared
Data Loader
BTSDL01
• Wire system as
legacy system
• Turn power OFF
prior to repair
• Use Bluetooth
®
Shared Data Loader
BTSDL01 for your
specic model
• Insert Bluetooth
®
Shared Data Loader
BTSDL01 BEFORE
turning power ON.
Bluetooth
®
Shared
Data Loader
BTSDL01 may be
removed after data
is loaded. Turn
power OFF before
removing Bluetooth
®
Shared Data Loader
BTSDL01
• Air conditioner/heat
pump fails to operate
• Air conditioner/heat
pump operating at
reduced performance
• Air conditioner/heat
pump operating at low
stage when expected
to operate at high
stage
• Integrated control
module diagnostic/
status LED display
shows the indicated
code
BLANK d 2 • System
mismatch
• Air conditioner/
heat pump is
wired as part of
a communicating
system and outdoor
unit requires
airow greater than
indoor unit’s airow
capability
• Shared data is
incompatible with
the system or
missing parameters
• Verify system type
(communicating or
legacy)
• Verify shared data
is correct for your
specic model;
re-populate data if
required
• Wire system as
legacy system.
• Turn power OFF
prior to repair
• Use Bluetooth
®
Shared Data Loader
BTSDL01 for your
specic model
• Insert Bluetooth
®
Shared Data Loader
BTSDL01 BEFORE
turning power
ON. Bluetooth
®
Shared Data Loader
BTSDL01 may be
removed after data
is loaded. Turn
power OFF before
removing Bluetooth
®
Shared Data Loader
BTSDL01
