Amana PHD48 User Manual

18
WARNING
TO AVOID PROPERTY DAMAGE, PERSONAL INJURY OR DEATH
DUE
TO FIRE, CLEARANCES TO COMBUSTIBLE SURFACES LISTED
AS
SHOWN MUST BE OBSERVED.
CLEARANCES
36"
Maximum
Overhang
48" Minimum
Overhang
36" Side
Clearance
for Servicing
Recommended
Minimum 9" Clearance
to Combustibles
36" Clearance for
Service Required
0" Minimum
Clearance to
Combustibles
Vinyl Coated
Canvas
Connections
Insulat
e
Return
Duct
Insulated
Supply
Duct
24" Clearance
(Condenser End)

Amana PHD48 Specifications

General

Brand	Amana
Model	PHD48
Category	Heat Pump
Language	English
