EN
18
Clogged hose (suction port)
1. Detach the hose handle (18) from the suction port (19) (Fig. 5).
2. Unscrew the suction port (19) (Fig. 21).
21
19
3. Remove any obstructions.
4. Ret the suction port (19) and the hose handle (18).
Clogged brush roll
1. Flip the appliance frontside down with the brush roll (9) facing outwards.
2. Unscrew the base plate to detach it from the brush cover (Fig. 22).
22
1
2
