22
Putting to operation
AMATRON II-A DB 599 09.01
5.1.3.3 Data selection
The display and entering possibilities of information
are divided into four data blocks, which can be
selected via the softkey keys
T1
to
T4
in the
display "menu selection" (Fig. 9).
The following data blocks are available at random:
• Data block
T1
( Job )
This data block combines the job related data, e.g.
name or description of the plot, the required value,
comments and the implement number. Apart from
the required value these data, e.g. worked area,
operational hours etc. are stored. By pressing key
T2
the job is started. From that time the opera-
tional hours are determined. At the end of the data
block the computer automatically returns into the
menu selection (see para. 6.1 / para. 7.1).
• Data block
T2
( Memory )
Data of up to 20 jobs can be stored. These are job
related data, as name, comment and data deter-
mined during operation (e.g. area, operational
hours, etc.) (please compare para. 6.4 / para. 7.4).
The data block "Memory" can only be left via the
key
T1
(menu).
With the key
T2
the memory can be deleted.
NOTE: All jobs in the memory will be reset.
• Data block
T3
( implement )
Here, all implement specific data are entered, as,
e.g. working width, calibration factors, hopper
content, etc. When all data inquiries have been
answered, the computer automatically returns to
the menu selection (please see para. 6.2 / para.
7.2).
• Data block
T4
( operation )
Here, the job-relevant data are displayed. When
the machine is in operational position the display
automatically changes to the data block "operation"
after approx. 10 seconds. Data like forward speed
and application rate are displayed (please compare
para. 6.3 / para. 7.3).
Further information can be inquired during the op-
erating procedure (for more detailed explanation,
please refer to para. 6.5 / para. 7.5).
