Operating sequence fertiliser spreader ZA-M
23
AMATRON II-A DB 599 09.01
6. Operating sequence fertiliser
spreader ZA-M
After the computer has been switched on and the
initial picture has appeared the display automati-
cally jumps into the data block "Job" after some
seconds.
Fig. 8
By pressing key
T1
(Menu) you can change to
"menu selection". Here four data blocks can be
selected.
Fig. 9
After every processing a complete data block the
display automatically returns to the menu selection.
When entering data, via the key
T1
, you can
change to the display "menu selection" at any time.
• By pressing key
T1
in the menu selection
you will return again to the data block "Job"
(see para. 6.1).
F
In this instruction manual the se-
quence of the chapters corresponds
to the sequence of the usual entering
of data. Following this sequence
helps to avoid entering mistakes.
6.1 Data block
T1
Job
6.1.1 Menu ‚ name / address‘
Fig. 10
Display of the job-number (Fig. 10/2), which is
automatically allocated by the on board computer.
The name (e.g. plot name) (Fig. 10/1) is entered
via the ten digit key board.
F
After termination the data entering in
one display always confirm by
pressing key
=
Eingabe
Input
as otherwise the
entered data will not be stored.
• By pressing key
T2
(Start), the job is started
(see para. 6.3.1). However, only press this key
after all data have been completely entered in
the different data blocks.
• By pressing key
T4
(Next), in the next dis-
play will appear the inquiry for the application
rate (see para 6.1.2).
6.1.2 Menu spread rate
Fig. 11
Via the 10 digit key board enter the spread rate
(kg/ha) as required value (equivalent to the quan-
tity which is intended to be constantly spread in
