Operating sequence fertiliser spreader ZA-M
29
AMATRON II-A DB 599 09.01
6.3 Data block
T4
operation
6.3.1 Starting the spreading operation
From the menu selection select data block "opera-
tion" via key
T4
.
In data block "job" or "operation" press key
T2
(start) tp get to the start routine.
Fig. 26
The spreading procedure starts by opening the
hydraulic shutter slide.
• During inquiry "start" the actual job can be
started by pressing key
T2
(yes) and the ac-
tual operational display appears (please see
Fig. 28/ para. 6.3.2).
• By pressing key
T3
(no) the start procedure
is reset and the following display appears:
Fig. 27
The job can again be started as described above.
6.3.2 Operational display
Fig. 28
On the operational display the forward speed (Fig.
28/1), the actual spread rate (Fig. 28/2) and the
setting of the keys
-10 %
+10 %
(Fig. 28/3) (corre-
sponds to the increased or reduced spread rate,
see para. 6.5.4) are shown.
• At the end of the operational procedure the job
can be terminated and stored (see para. 6.3.5)
by pressing key
T2
(End).
• By pressing key
T3
(Bin) you will receive
information about the hopper content (see para.
6.3.3).
• By pressing key
T4
(% both) the individual
shutter slides (r.h. or l.h.) or both (total) can be
selected. Here it is possible to change the
spread rates via the keys
-10 %
+10 %
(see
para. 6.5.4).
6.3.3 Menu "hopper"
Fig. 29
This menu provides you with information about the
entered spread rate (required value) (Fig. 29/1), a
prediction about the remaining distance (m) (Fig.
29/2) and the worked area (ha) (Fig. 29/3) as well
